Drafting Services

Our Expertise

• Complete 3D model, all disciplines

• Brownfields and Greenfields. As-building

• 3D Laser Scan, Drone and other survey data incorporation

• Vendor data and 3D model incorporation

• Modular, transportable, field weld free design

• 3D Model Design, Operability and Constructability reviews

• Virtual Reality

• Animation

Process Synergy specializes in CAD design and drafting services, adding significant value to project execution through precise and efficient 3D drafting and modeling. Our expertise in using advanced CAD platforms ensures greater accuracy, enhancing the operability, maintainability, and constructability of projects. We leverage modern CAD tools to automatically generate essential project documents such as Material Take-Offs, Weld Maps, and Equipment Lists. This automation streamlines the design, tender, and construction processes, reducing errors and improving overall project efficiency. By providing detailed 3D models and comprehensive documentation, Process Synergy ensures smoother project execution from concept to completion.

Design drafting disciplines include:

• Process

• Mechanical

• Instrumentation

• Electrical

• Civil/Structure

• Automation and SCADA
